Universal Truck Door Retainer Aluminium Body Length 490mm Arm Length 280mm

Description

The universal galvanized truck door locator is a specialized hardware accessory for freight trucks, with core parameters of a main body length of 545mm and an arm length of 432mm, and a surface treated with galvanized rust prevention.
Core Features
The main body is made of galvanized steel, which has strong rust and corrosion resistance, and is suitable for high-frequency bumps and outdoor use scenarios such as trucks. It can stably fix the car door in the open state to avoid accidental closing and collision during driving.
Adaptation scenario
Widely used in box trucks, freight trailers, engineering trucks and other vehicle models, it is a commonly used supporting hardware for logistics transportation vehicles and can replace old door positioning accessories of the same specifications.

Performance and installation parameters
Load bearing limit: It can support heavy-duty box doors up to 120kg and is suitable for the vast majority of cargo vehicles with a length of 4.2 meters or more.
Installation hole position: Standard configuration includes 4 sets of M8 standard installation holes, with hole spacing suitable for mainstream commercial vehicle door reserved installation positions, without the need for additional hole expansion.
Working temperature range: -40 ℃~+70 ℃, suitable for outdoor transportation conditions in most regions of China.
Rust proof grade: Salt spray test can achieve 48 hours without rust, and long-term outdoor use is not prone to rust and sticking problems.
Opening and closing lifespan: Under normal usage scenarios, the opening and closing times can reach over 50000 times, and the durability is much higher than that of ordinary iron locators.
